Multifunction Electrical Tester Calibrator
Factory Settings
31
Factory Settings
Table 8 lists the setup functions and their respective factory set values.
Table 8. Factory Settings
Setup Item Factory Set Value
Volume 15
Brightness 6
Beeper ON
Calibration password 2235
Time GMT
Date GMT
Voltage calibrator Yes/No
Loop Compensator Yes/No
Calibrator GND ON
High resistance source GND ON
R multiplier input 0 MΩ
Low resistance source GND ON
Loop impedance correction OFF
Loop impedance MAN value 0.000 Ω
Loop impedance SCAN value 0.000 Ω
Loop Series Resistance 0.000 Ω
[1]
Line impedance correction OFF
Line impedance MAN value 0.000 Ω
[1]
Line impedance SCAN value 0.000 Ω
[1]
Line Series Resistance 0.000 Ω
[1]
Substitute LC Rout 2.000 Ω
RCD I level 90 %
RCD series resistance R1
Meter GND OFF
[1] Set to an instrument unique resistance value during initial calibration.
