5322A
Operators Manual
62
Table 11. Series Resistance Values
Resistor Label Resistor Value
R01 0.02 Ω
R02 0.05 Ω
R03 0.1 Ω
R04 0.35 Ω
R05 0.5 Ω
R06 0.9 Ω
R07 1.7 Ω
R08 5 Ω
R09 9 Ω
R10 17 Ω
R11 47 Ω
R12 90 Ω
R13 170 Ω
R14 470 Ω
R15 900 Ω
R16 1.7 kΩ
Trip Current Calculation
The measured trip current can be displayed either as the actual measured
current in mA or recalculated to a nominal line voltage of 230 V or 240 V. Setting
of the type of reading can be changed in the Setup>RCD, and the Trip time
calculation parameter. The appropriate type is always displayed after the
reading.
Use the Trip current calculation in the Setup>RCD menu to change the behavior:
1. Push the Setup softkey.
2. With the cursor keys or rotary knob, highlight the RCD selection and either
push the Select softkey or push in the rotary knob.
3. Use the cursor keys or rotary knob to highlight Trip current calculation and
either push the Select softkey or push in the rotary knob.
4. Use the cursor keys or rotary knob, highlight the desired parameter to either
OFF to leave the output terminals disconnected or Reconnect to enable
repeated line voltage connections.
5. Push the Select softkey or push in the rotary knob.
6. Push the Exit softkey several times to return to the RCD calibration main
screen.
