5320A
Users Manual
5-12
Table 5-4. SOURce Command Summary (cont.)
Command Description
[:LEVel] <DNPD> Sets the Low Resistance value.
[:LEVel]? Returns the set value for the Low Resistance mode.
:LOW {GROund|FLOat} Connects or disconnect the Low terminal to ground.
:LOW? Returns status of the Low Terminal grounding.
:SENSe {ON|OFF} Selects between 4-wire and 2-wire resitance mode.
:SENSe? Returns ON when 4-wire is selected and OFF when 2-wire
is selected.
:CURR? Returns the current flowing through the selected
resistance.
[:CURR]:LIMit? Returns the maximum current allowed to flow through the
resistance.
:IDPassive Sets Calibrator to Passive Leakage Current Mode.
[:CURRent]:NOMinal <DNPD> Sets the Passive Leakage Current value.
[:CURRent]:NOMinal? Returns the nominal Passive Leakage Current Value.
[:CURRent]:INSTant? Returns instantaneous current flowing through the
Calibrator.
[:CURRent]:RESulting? Returns resulting measured UUT current.
:IDDifferential Sets Calibrator to Differential Leakage Current Mode.
[:CURRent]:NOMinal <DNPD> Set the Differential Leakage Current value.
[:CURRent]:NOMinal? Returns the nominal Differential Leakage Current value.
[:CURRent]:INTstant? Returns instantaneous current flowing through the
Calibrator.
[:CURRent]:RESulting? Returns resulting measured UUT current.
:RCDT Path to RCD Trip Time mode.
:TIME <DNPD> Set the trip time for the RCD Trip Time mode.
:TIME? Returns the set trip time for the RCD Trip Time mode.
:CURRent? Returns the measured trip current.
:RPOSition <DNPD> Selects one of the 16 resistances available in the RCD
Time function.
:RPOSition? Returns the index value of the selected resistance.
[:CURRent]:NOMinal <DNPD> Sets the nominal trip current value for the RCD Trip Time
Mode.
[:CURRent]:NOMinal? Returns the nominal trip current value.
[:CURRent]:MULTiplier <CPD> Sets the trip current multiplier.
[:CURRent]:LEVel <CPD> Sets the I level value.
