5320A
Users Manual
5-14
Table 5-4. SOURce Command Summary (cont.)
Command Description
:CURRent? Returns measured current flowing through selected
resistance.
:CLEar Clears the maximum value of peak current.
[:CURRent]:PFC? Returns Prospective Fault Current value.
:MANual <DNPD> Sets the Manual residual impedance value.
:MANual? Returns the set Manual residual impedance value.
:SCAN? Returns the Scanned loop impedance value.
:VOLTage Path to Voltage Calibration mode.
[:LEVel] [<DNPD>] Sets the voltage value for the voltage calibration mode.
[:LEVel]? Returns the set voltage value for voltage calibration mode.
:CURRent? Returns the measured load current value.
:FREQuency <DNPD> Set the Frequency for the AC voltage calibration mode.
:FREQuency? Returns the set Frequency for the AC voltage calibration
mode.
:FUNCtion {DC|AC} Sets the Function of the output voltage.
:FUNCtion? Returns the Function of the output voltage.
:LOW {GROund|FLOat} Connects or disconnects Calibrator LO terminal to/from
ground.
:LOW? Returns the status of the LO Terminal connection to
ground.
:METer Path to Meter function.
:FUNCtion {DC|AC} Sets the Multimeter Function.
:FUNCtion? Returns the Multimeter Function setting.
:PROBe {OFF|10KV|40KV} Sets HV probe for voltmeter.
:PROBe? Returns the HV probe setting for voltmeter.
:LOW <CPD> Connects or disconnects Multimeter LO terminal to or from
ground.
:LOW? Returns the status of the Multimeters LO terminal
connection to gound.
:CURRent? Returns the measured current by the ammeter.
:POWer? Returns the measured power value.
:VOLTage? Returns the measured voltage value.
:HIPL Path to HIPOT leakage current function.
:FUNCtion {DC|AC} Sets the HIPOT leakage current mode: ac or dc.
