Accessories
The following accessories are included with the 8200HP:
• 1 right angle combined power/data cable
• 1 GPS antenna type Z Plus
• 1 antenna cable (5 meters)
• 1 magnetic antenna mount
• A CD containing PC utilities and product documentation
Figure 1: 8200HP Back End
Name Description
A
DC power input, RS-232 signals, CAN signals and
auxiliary strobe signal
B
DC power input, RS-232 signals, CAN signals and
auxiliary strobe signal
ANT Antenna connection
Table 1: 8200HP Interfaces
