OmniSTAR 8200HP User Manual
Issue 1.07, 10/2008
56
Power requirements
Voltage +10 to +32 VDC
Power consumption 4.2 W (typical)
RF input / LNA power output
Antenna connector TNC female, 50 î nominal impedance
RF Input Frequencies 1575.42 MHz (L1), 1227.60 MHz (L2),
1525 MHz â 1559 MHz (L-Band)
LNA Power + 9 VDC
Input / output data interface
Electrical Format RS232 / CAN 2.0B
Bit Rate
1
4800, 9600, 19200, 38400, 57600, 115200 bps
Lead input CTS and DTR
Lead output RTS and PPS
Signals Supported TX, RX, RTS, CTS, DTR, PPS
Input / output connectors
A Power/Data port A
B Power/Data port B/C
Ant Antenna
Physical dimensions
Size 147.8 (w) x 55.8 (h) x 215.9 mm (d)
Weight 1.05 kg
1
Most external hardware using GPS NMEA-messages is set to use 4800 bps,
8 databits, 1 stopbit and no parity (8N1).
