OmniSTAR 8200HP User Manual
Issue 1.07, 10/2008
16
Display Description
NoSgnl
The signal of the selected satellite is too weak to be received,
or the wrong differential satellite has been selected.
Updtng
The receiver is updating its almanac data from the selected
satellite
Om-VBS
The receiver has valid OmniSTAR VBS data and is set to VBS
mode only.
Static
The receiver has detected it is stationary and is using this
information to aid the convergence of the position.
A:xxx
The estimated position error (1 sigma) of the HP/XP position
solution (meters/feet or centimeters/inches).
B:AUTO
Backup differential mode is set to automatic (only possible
when the receiver is in HP/XP mode).
B: VBS
Differential mode falls back to VBS in case HP/XP mode
should fail (only possible when the receiver is in HP/XP mode)
Table 3: Differential information
The 8200HP menu structure
The menu structure of the 8200HP consists of 3 top-level menu screens. Each
top-level menu screen links to one or more sub-menu screens. Each sub-
menu screen links sequentially to a number of information/configuration
screens. Cycling through the top-menu screens is done by pressing the
button repeatedly. The order of the top level menu is Home screen – Status
screen – Configuration screen – Home screen.
Pressing the
button from one of the top-level menu screens will enter the
corresponding sub-menu. Cycling through the sub-menu screens of a certain
sub-menu is again done by pressing the
button repeatedly. To return to the
top-level menu screen, press the button.
The information/configuration screens under a certain sub-menu can be
accessed by pressing the
button. To cycle through the screens, use the
and buttons. In some screens, information can be edited. These
screens show a small ‘CFG’ in the top left corner of the screen. To enter edit
mode, press
until the cursor blinks on the first character of the information
to be edited. To leave edit mode, press
. Other screens can show more
information than fits the screen. These screens show a small ‘‘ sign in the top
