OmniSTAR 8200HP User Manual
Issue 1.07, 10/2008
53
NMEA 2000 Msg Rate
Figure 103: NMEA 2000 message rates
The NMEA 2000 Msg Rate configuration controls the message rate of each
NMEA 2000 message output to the CAN bus. It is similar to the CAN bus
message rates configuration. The default message rates of the different NMEA
2000 messages are listed in Table 8.
Message Default message rate
PRU 01.0
VEL 01.0
DOP 01.0
GSV 05.0
GDS 01.0
GDI 05.0
CFG 05.0
INF 60.0
STM 05.0
TAD 01.0
GPN 05.0
POS 01.0
Table 8: NMEA 2000 default message rates
TPCAN Protos
Figure 104: TPCAN protos
The TPCAN Protos screen is used to control the use of TSIP over the CAN
bus. Default, TSIP over the CAN bus is enabled.
