Fuji Electric FRENIC MEGA G2 Series - Page 367

5.3 Description of Function Codes 5.3.2 E codes (Extension terminal functions)
5-183
FUNCTION CODES
Chap 5
FUNCTION
CODES
F Codes
E Codes
C Codes
P Codes
H Codes
A Codes
b Codes
r Codes
J Codes
d Codes
U Codes
y Codes
K Codes
E52
Keypad menu selection
E52 provides a choice of three menu display modes for the standard keypad as listed below.
E52 data
Menu display mode
Menus to be displayed
0
Function code data editing mode
Menus #0, #1 and #7
1
Function code data check mode
Menus #2 and #7
2
Full-menu mode
Menus #0 through #7
Selects the menus displayed on the standard keypad. There are eight menus as shown in the table below.
Menu #
LED monitor
indication
Function
Displayed content
0
0.fnC
Quick setup
Quick setup function code
1
1.f__
Data setting F to o
F to o group function code
2
2.rep
“Data Checking”
Modified function code
3
3.ope
Run monitor
Operation status indication
4
4.i_o
I/O check
DIO, AIO status indication
5
5.CHe
Maintenance
Maintenance information indication
6
6.al
Alarm Information
Alarm information indication
7
7.Cpy
Data copy
Copy function (option keypad only)
8
8.des
Destination setting
This is not used for machines for use in
Japan.
 For details on the content of each menu item, refer to Chapter 3 “OPERATION USING THE KEYPAD”.
E54
Frequency detection 3 (level) (Refer to E31)
For details, refer to the description of E31.
E55, E56
Current detection 3 (level and timer) (Refer to E34)
For details, refer to the description of E34.
