5.3 Description of Function Codes 5.3.5 H codes (High performance functions)
Starting mode (Auto search delay time 1) (Refer to H09)
For details, refer to the description of H09.
Non-linear V/f 1 (Frequency and voltage) (Refer to F04)
Non-linear V/f 2 (Frequency and voltage)
For details, refer to the description of F04.
Acceleration/Deceleration time (Jogging) (Refer to F07)
Deceleration time for forced stop
1st/2nd S-curve acceleration/deceleration range
For details, refer to the description of F07.
UP/DOWN control (Initial frequency setting) (Refer to F01)
For details, refer to the description of F01.
Low limiter (Mode selection) (Refer to F15)
For details, refer to the description of F15.
Low limiter (Lower limiting frequency)
H64 specifies the lower limit of frequency to be applied when the current limiter, torque limiter, or overload prevention
control is activated. Basically, there is no need to modify the default setting.
• Data setting range: 0.0 to 60.0 (Hz)
Non-linear V/f 3 (Frequency and voltage) (Refer to F04)
The non-linear V/f pattern setting is described in detail in the function code F04 section.
Auto energy saving operation (Mode selection) (Refer to F37)
The auto energy-saving operation (mode selection) setting is described in detail in the function code F37 section.
Slip compensation 1 (Operating conditions selection) (Refer to F42)
For details, refer to the description of F42.
