5.3 Description of Function Codes 5.3.5 H codes (High performance functions)
Refer to Chapter 4 “4.4 Destination Setting” . There is no need to change the setting on products for Japan.
Anti-regenerative control (Operation level) Related function code: H69
This function code is described in detail at the H69 item.
H116
H117
H118
H119
H120
H121
Forced operation (Fire Mode) (Operation selection)
(Confirmation time)
(Set frequency)
(Run direction)
(Starting method)
(Waiting time)
Set when wishing to enable forced operation (Fire Mode). With forced operation, the motor can be forcibly run at
the specified speed. Even if an alarm occurs during forced operation, operation can be continued. If an alarm occurs
due to a protective function such as OC (instantaneous overcurrent protection), operation is resumed with automatic
reset. The time until operation is resumed can be set. If switching to forced operation, “Fod” is recorded in the alarm
history for the purpose of retaining a record. If continuing operation with forced operation, alarms that are
automatically reset are not recorded in the alarm history.
By assigning “FMS” to a digital input terminal and turning “FMS” ON, forced operation (Fire Mode) is enabled.
(Function code E01 to E09, data = 134)
By assigning “FMRUN” to a digital output terminal, it turns ON during forced operation. (Function code E20 to E24,
E27, data = 95)
By selecting automatic reset with forced operation, the inverter will continue to run with no protective
functions, resulting in a risk of inverter damage or fire, etc.
