In this guide, the duplex automatic document feeder is referred to as the “document feeder” or "DADF".
No. Component Function
1 Lever Turn this lever to clear paper jams.
2 Left cover Open this cover to clear paper jams.
3 Inner cover Open this cover to clear paper jams.
4 Document guides Use these guides to align the edges of documents.
5 Document feeder tray Load documents here.
6 Document stopper Prevents outputs from falling off.
7 Document output tray Scanned documents are delivered here.
8 Document glass Scans a loaded document.
