Scanner Environment Settings
376
Scanner Environment Settings
9
Configuration of Job Flow Sheets
This section describes how to configure the machine to use the Job Flow Sheets service.
"Step 1 Enabling Ports and Setting up TCP/IP" (P.376)
"Step 2 Configuring the SNMP Port" (P.376)
"Step 3 Configuration on the Computer" (P.376)
Step 1 Enabling Ports and Setting up TCP/IP
To use the Job Flow Sheets service, enable the SOAP, SNMP, and Internet Services(HTTP)
ports, and set an IP address and other addresses. The following describes the configuration
procedures on the machine.
z
You can configure the settings using CentreWare Internet Services. For information on how to use
CentreWare Internet Services, refer to "Configuring Machine Settings Using CentreWare Internet Services"
(P.331).
Step 2 Configuring the SNMP Port
Configure the transport protocol for the SNMP port using CentreWare Internet Services.
1
Start CentreWare Internet Services
z
For information on how to start CentreWare Internet Services, refer to "Starting CentreWare Internet Services" (P.330).
2
Configure the transport protocol for the SNMP port.
1) Click the [Properties] tab.
2) Click [Connectivity].
3) Click [Port Settings].
4) Select the [UDP] check box under [SNMP].
5) Click [Apply].
6) The right frame of the web browser changes to the machine reboot display.
7) Click [Reboot Machine]. The machine reboots and the settings are enabled.
Step 3 Configuration on the Computer
Create job flows using Device Setup Tool to use for scanned documents.
z
Device Setup Tool is included in ApeosWare Management Suite, which you can download from our Web site.
To Next Page
