Target Select the target (port) to associate with the group.
The Backpanel Locations section displays a graphical
representation of the Fibre Channel and Ethernet ports as
they appear on the rear of the system. A dark border
displays around the currently selected target.
To change the LUN numbers assigned to a device, or to map virtual devices to a host,
use the Configuration > VTL > Host Access > Host Mapping page (see "Remote
Host Mapping" on page 233).
2. (Optional) Select the Use CCL check box to use the Command and Control LUN.
The CCL (Command and Control LUN) is not used in most environments. This
option is recommended for host access groups that contain an HP-UX host. It can
also be used if hosts that are not assigned to any host access group exist in the
SAN. The CCL is accessible to hosts only through LUN 0.
CAUTION!
If you are not sure if you should use CCL, contact Fujitsu Technology Solutions
Customer Support before you enable this option.
3. Click Add.
4. (Optional) To map additional hosts, repeat Steps 1–3.
5. Click Next to continue.
Figure 109: VTL Wizard: Map Remote Hosts
ETERNUS CS800 161
8 Configuration Wizards
