404 iRMC S2/S3
IPMI OEM Commands supported by the iRMC S2/S3
F5 12 - Get EEPROM Version Info
This command returns information on the current versions (bootloader,
firmware and SDR) stored in the EEPROM(s).
Request Data - B8 NetFnlLUN: OEM/Group
- F5 Cmd : Command Group Memory
1:3 80 28 00 IANA-Enterprise-Number FTS, LS byte first
4 12 Command Specifier
5 EEPROM# 00=EEPROM 1; 01=EEPROM 2
Response Data - BC
- F5
1 Completion Code
2:4 80 28 00 IANA-Enterprise-Number FTS, LS byte first
5 Status 00=Checksum Error Runtime FW, 01=OK
6 Major FW Revision Binary coded
7 Minor FW Revision BCD coded
8:10 Aux. FW Revision Binary coded (major/minor/res.)
11 Major FW Revision ASCII coded letter
12 Major SDRR Revision BCD coded
13 Minor SDRR Revision BCD coded
14 SDRR Revision Char. ASCII coded letter
15 SDRR-ID LSB binary coded
16 SDRR-ID MSB binary coded
17 Major Booter Revision Binary coded
18 Major Booter Revision BCD coded
19:20 Aux. Booter Revision Binary coded (major/minor)
