86 iRMC S2/S3
Prerequisites
5.1 Requirements:
Check the AVR settings
Check the following important settings before using AVR:
Graphics mode settings on the managed server
AVR supports the following graphics modes:
I If a high-resolution graphics mode is set on the server (shown on a gray
background in the table), this is shown on the iRMC S2/S3 web interface.
I Only VESA-compliant graphics modes are supported.
Resolution Refresh rates
[in Hz]
Maximum
color depth
[bits]
640 x 480 (VGA) 60; 75; 85 32
800 x 600 (SVGA) 56; 60; 72; 75; 85 32
1024 x 768 (XGA) 60; 70; 75; 85 32
1152 x 864 60; 70; 75 32
1280 x 1024 (UXGA) 60; 70; 75; 85 16
1280 x 1024 (UXGA) 60 24
1600 x 1200 (UXGA) 60; 65 16
1680 x 1050
1
1
iRMC S3 only
60 16
1920 x 1080
1
60 16
1920 x 1200
1
60 16
Table 3: Supported display settings
