Chapter 2 Setting Up XSCF 2-157
FIGURE 2-4 and FIGURE 2-5 show XSB hardware configuration diagrams in the
midrange servers. The number of hardware resources depends on whether the PSB
type is a Uni-XSB or Quad-XSB.
FIGURE 2-4 and FIGURE 2-5 are examples when two
CMUs are mounted on the MBU.
FIGURE 2-4 XSB Configuration Diagram (Uni-XSB) (In the Midrange Servers)
When PSB#n is Uni-XSB type
CMU IOU
XSB#00-0
XSB#01-0
MBU
Memory
Memory
Memory
Memory
Memory
Memory
Memory
Memory
I/O device
I/O device
I/O device
I/O device
