2-158 SPARC Enterprise Mx000 Servers XSCF User’s Guide January 2012
FIGURE 2-5 XSB Configuration Diagram (Quad-XSB) (In the Midrange Servers)
When PSB#n is Quad-XSB type
CMU IOU
XSB#00-2
XSB#00-3
XSB#00-0
XSB#00-1
XSB#01-2
XSB#01-3
XSB#01-0
XSB#01-1
MBU
CPU
CPU
CPU
CPU
CPU
CPU
CPU
CPU
Memory
I/O device
I/O device
I/O device
I/O device
Memory
Memory
Memory
Memory
Memory
Memory
Memory
