Fujitsu SPARC EnterpriseM3000 User Manual

Chapter 2 Setting Up XSCF 2-159
FIGURE 2-6 and FIGURE 2-7 show XSB hardware configuration diagrams in the
high-end servers. The number of hardware resources depends on whether the PSB
type is a Uni-XSB or Quad-XSB.
FIGURE 2-6 shows Uni- XSB hardware configuration diagrams in high-end servers.
FIGURE 2-6 XSB Configuration Diagram (Uni-XSB) (In the High-End Servers)
XSB#xx-0
IOU#nCMU#n
When PSB#n is Uni-XSB type
Memory
I/O device
Memory
Memory
Memory
I/O device
I/O device
I/O device
