2-160 SPARC Enterprise Mx000 Servers XSCF User’s Guide • January 2012
FIGURE 2-7 shows Quad-XSB hardware configuration diagrams in high-end servers.
FIGURE 2-7 XSB Configuration Diagram (Quad-XSB) (In the High-End Servers)
XSB#xx-3
XSB#xx-2
XSB#xx-1
XSB#xx-0
Memory
I/O device
Memory
Memory
Memory
I/O device
I/O device
I/O device
IOU#nCMU#n
When PSB#n is Quad-XSB type
