12.2.3 Administration
In this menu, you make general settings for a VLAN. The options must be configured sep-
arately for each bridge group.
Fig. 60: LAN->VLANs->Administration
The LAN->VLANs->Administrationmenu consists of the following fields:
Fields in the Bridge Group br<ID> VLAN Options menu
Field Description
Enable VLAN Enable or disable the specified bridge group for VLAN.
The function is enabled with #/.
The function is not activated by default.
Management VID Select the VLAN ID of the VLAN in which your device is to oper-
ate.
Funkwerk Enterprise Communications GmbH
12 LAN
bintec Rxxx2/RTxxx2 155
