Chapter 24 Monitoring
This menu contains information that enable you to locate problems in your network and
monitor activities, e.g. at your device's WAN interface.
24.1 Internal Log
24.1.1 System Messages
In the Monitoring->Internal Log->System Messages menu, a list of all internally stored
system messages is displayed. Above the table, you'll find the configured Maximum Num-
ber of Syslog Entries and the configured Maximum Message Level of Syslog Entries.
These values can be changed in the System Management->Global Settings->System
menu.
Fig. 204: Monitoring->Internal Log->System Messages
Values in the System Messages list
Field Description
No. Displays the serial number of the system message.
Date Displays the date of the record.
Time Displays the time of the record.
Level Displays the hierarchy level of the message.
24 Monitoring Funkwerk Enterprise Communications GmbH
506 bintec Rxxx2/RTxxx2
