11.5 SHDSL
bintec R3802 has an integrated SHDSL modem. The device supports G.SHDSL according
to ITU-T recommendations G.991.2 Annex A and B and SHDLS.bis according to G.991.2
Annex F and G. Depending on the device type and configuration the gateway transmits the
data over a pair of wires at up to 5696 kbps, over two pairs of wires at up to 11392 kbps,
over three pairs of wires at up to 17088 kbps or over four pairs of wires at up to 22784
kbps.
11.5.1 SHDSL Configuration
In the SHDSL menu you configure the SHDSL interface of your device.
Note
Ask your provider about any special features of your SHDSL connection.
Note
Agree the connection conditions for back-to-back connections (campus connect) with
your remote terminal.
The SHDSL interfaces can be configured separately or as a bundle.
Choose the button to edit the predefined SHDSL interfaces. In the ex works state, the
logical SHDSL interfaces -&/! to -&/!' are each preset with one pair of wires.
11 Physical Interfaces Funkwerk Enterprise Communications GmbH
142 bintec Rxxx2/RTxxx2
