Field Description
Possible values:
• 01-2 0 (default value): The ADSL mode is auto-
matically adapted for the remote terminal.
• 01-2 :ADSL1 / G.DMT is used.
• 01-2: ADSL2 / G.992.3 is used.
• 01-2 /&: ADSL2 Plus / G.992.5 is used.
• %: The ADSL interface is not active.
Only for ADSL Mode = 0= 0
• 0 0=!(": The ADSL mode is automatically
adapted to the other end with reference to G.992.3 Annex M.
• 01-2 /& 0=!(": ADSL2 Plus / G.992.3 Annex M
is used.
• 0*- +': ANSI T1.413
Only for ADSL Mode = 0= >
• +- +': ETSI T1.413
Transmit Shaping
Select whether the data rate in the send direction is to be re-
duced. This is only needed in a few cases for special DSLAMs.
Possible values:
• 1/ 2 -,": The data rate in the send direc-
tion is not reduced.
• E #,& to EE #,&: The data rate in the send
direction is reduced to a maximum of 128,000 bps to
2,048,000 bps in defined steps.
• 3&!:The data rate is reduced to the value entered
in Maximum Upstream Bandwidth.
The default value is 1/ 2 -,".
Maximum Upstream
Bandwidth
Only for Transmit Shaping = 3&!
Enter the maximum data rate in the send direction in bits per
second.
Funkwerk Enterprise Communications GmbH
11 Physical Interfaces
bintec Rxxx2/RTxxx2 141
