Field Description
• 0*- +': ANSI T1.413
• 01-2: ADSL classic, G.DMT, ITU G.992.1
• / : Splitterless ADSL, ITU G.992.2
• 01-2: G.DMT.Bis, ITU G.992.3
• 01-2 12+: ADSL2 Double Ended Line Test
• 01-2 /&: ADSL2 Plus, ITU G.992.5
• 01-2 /& 12+: ADSL2 Plus Double Ended Line Test
• ;01-2: Reach Extended ADSL2
• ;01-2 12+: Reach Extended ADSL2 Double Ended Line
Test.
• 01-2 +3!+ ' 0= (
• 01-2< +3!+  0= (
Fields in the Current Line Speed menu
Field Description
Downstream Displays the data rate in the receive direction (direction from
CO/DSLAM to CPE/router) in bits per second.
The value cannot be changed.
Upstream Displays the data rate in the send direction (direction from CPE/
router to CO/DSLAM) in bits per second.
The value cannot be changed.
Fields in the DSL Parameter menu
Field Description
DSL Mode
Define which Annex of ITU-T Recommendation G.991.2 is used
for the connection.
Possible values:
• 0= 0: For applications in North America
(provider-dependent).
• 0= > (default value): For applications in Europe
(provider-dependent) for example.
DSL SyncType Select the ADSL synchronization type.
