Field Description
packets (indicated in decimal format).
• +?- >) 8/: The TOS value is specified in binary
format, e.g. 00111111.
• +?- 1%/ 8/: The TOS value is specified in decimal
format, e.g. 63.
Set COS value
(802.1p/Layer 2)
Here you can set/change the service class (Layer 2 priority) in
the VLAN Ethernet header of the IP packets, based on the class
(Class ID) that has been defined.
Possible values are whole numbers between and ..
The default value is &.
Interfaces Only for Class map = *.
When creating a new class plan, select the interfaces to which
you want to link the class plan. A class plan can be assigned to
multiple interfaces.
14.4.3 QoS Interfaces/Policies
In the Networking->QoS->QoS Interfaces/Policies menu, you set prioritisation of data.
Note
Data can only be prioritized in the outgoing direction.
Packets in the high-priority class always take priority over data with class IDs 1... 254.
It is possible to assign or guarantee each queue and thus each data class a certain part of
the total bandwidth of the interface. In addition, you can optimise the transmission of voice
data (real time data).
Depending on the respective interface, a queue is created automatically for each class, but
only for data traffic classified as outgoing and for data traffic classified in both directions. A
priority is assigned to these automatic queues. The value of the priority is equal to the
value of the class ID. You can change the default priority of a queue. If you add new
queues, you can also use classes in other class plans via the class ID.
Funkwerk Enterprise Communications GmbH
14 Networking
bintec Rxxx2/RTxxx2 211
