13.3.3.1 Edit or New
Choose the icon to edit existing entries. Choose the Newbutton to configure additional
wireless networks.
Fig. 67: Wireless LAN Controller->Slave AP configuration->Wireless Networks
(VSS)->New
The Wireless LAN Controller->Slave AP configuration->Wireless Networks
(VSS)->New menu consists of the following fields:
Fields in the Service Set Parameters menu
Field Description
Network Name (SSID) Enter the name of the wireless network (SSID).
Enter an ASCII string with a maximum of 32 characters.
Also select whether the Network Name (SSID) is to be trans-
mitted.
The network name is displayed by selecting 8&#/.
It is visible by default.
Intra-cell Repeating Select whether communication between the WLAN clients is to
Funkwerk Enterprise Communications GmbH
13 Wireless LAN Controller
bintec Rxxx2/RTxxx2 175
