Feld Beschreibung
Group Description
Displays the description of the interface group.
Distribution Policy Displays the selected mode of the data traffic.
Fields in the Interface Selection for Distribution menu
Field Description
Interface Select the interfaces that are to belong to the group from the
available interfaces.
Distribution Ratio Enter the percentage of the data traffic to be assigned to an in-
terface.
The meaning differs according to the employed Distribution
Ratio:
• -&&!;!;# is based on the number of distrib-
uted sessions.
• For 2!, > the data rate is the de-
cisive factor.
The menu Advanced Settings consists of the following fields:
Fields in the Advanced Settings menu
Field Description
Route Selector The Route Selector parameter is an additional criterion used
for a more precise definition of load balancing groups. The inter-
face entry within a load balancing group is extended by a rout-
ing information. The Route Selector is required in certain applic-
ations in order to unambiguously assign the router managed IP
sessions to the load balacing groups. The following rules apply
to the usage of this parameter:
• If an interface is assigned only to one load balancing group,
configuration of the Route Selector is not required.
• If an interface is assigned to several load balancing groups,
configuration of the Route Selector is mandatory.
• Within a given load balancing group, the Route Selector has
to be identical for all interface entries.
Select the Destination IP Address of the desired route.
14 Networking Funkwerk Enterprise Communications GmbH
200 bintec Rxxx2/RTxxx2
