Field Description
Destination IP Ad-
dress/Netmask
Enter the destination IP address and netmask of the data pack-
ets.
Possible values:
• 0) (default value)
• @&: Enter the IP address of the host.
• *: Enter the network address and the related net-
mask.
Destination Port/Range
Only if Protocol = +4, 31
Enter the destination port number or range of destination port
numbers that matches the filter.
Possible values:
• !0//! (default value): The filter is valid for all port numbers
• -,%) ,: Enables the entry of a port number.
• -,%) , $: Enables the entry of a range of port
numbers.
Source IP Address/
Netmask
Enter the source IP address and netmask of the data packets.
Source Port/Range
Only if Protocol = +4, 31
Enter the source port number or range of source port numbers.
Possible values:
• !0//! (default value): The filter is valid for all port numbers
• -,%) ,: Enables the entry of a port number.
• -,%) , $: Enables the entry of a range of port
numbers.
DSCP/TOS Filter
(Layer 3)
Select the Type of Service (TOS).
Possible values:
• $ (default value): The type of service is ignored.
• 1-4 >) 8/: Differentiated Services Code Point
according to RFC 3260 is used to signal the priority of IP
packets (indicated in binary format, 6 bit).
14 Networking Funkwerk Enterprise Communications GmbH
222 bintec Rxxx2/RTxxx2
