Fig. 122: WAN->Real Time Jitter Control->Controlled Interfaces->New
The menu WAN->Real Time Jitter Control->Controlled Interfaces->New consists of the
following fields:
Fields in the Basic Settings menu
Field Description
Interface Define for which interfaces voice transmission is to be optim-
ised.
Control Mode Select the mode for the optimisation.
Possible values:
• 4// ;+ -& /) (default value): By
means of the data routed via the media gateway, the system
detects voice data traffic and optimises the voice transmis-
sion.
• 0// ;+ -&: All RTP streams are optimised.
• %: Voice data transmission is not optimised.
• 0/)&: Voice data transmission is always optimised.
Maximum Upload
Speed
Enter the maximum available upstream bandwidth in kbps for
the selected interface.
17 WAN Funkwerk Enterprise Communications GmbH
312 bintec Rxxx2/RTxxx2
