Field Value
to the available total working memory in MByte. The usage is
also displayed in brackets as a percentage.
ISDN Usage Internal Shows the number of active B channels and the maximum num-
ber of available B channels for internal connections.
ISDN Usage External Shows the number of active B channels and the maximum num-
ber of available B channels for external connections.
Active Sessions (SIF,
RTP, etc... )
Displays the total of all SIF, TDRC, and IP load balancing ses-
sions.
Active IPSec Tunnels Displays the number of currently active IPSec tunnels in relation
to the number of configured IPSec tunnels.
Fields in the Modules menu
Field Value
DSP Module Shows the type of plugged DSP module if any. An acquired fax
licence, if any, can be displayed.
Fields in the Physical Interfaces menu
Field Value
Interface - Connection
Information - Link
The physical interfaces are listed here and their most important
settings are shown. The system also displays whether the inter-
face is connected or active.
Interface specifics for Ethernet interfaces:
• IP address
• Netmask
• Not configured
Interface specifics for ISDN interfaces:
• Configured
• Not configured
Interface specifics for xDSL interfaces:
• Downstream/Upstream Line Speed
Fields in the WAN Interfaces menu
Field Value
Description - Connec- The WAN interfaces are listed here and their most important
Funkwerk Enterprise Communications GmbH
10 System Management
bintec Rxxx2/RTxxx2 79
