2. OPERATIONAL OVERVIEW
2-3
2.2.1 Key description
Note: In telex, lower case, #, &, *, $, @, %, etc. are not permitted. A full list of charac-
ters usable in telex appears in the Appendix. For e-mail all characters and symbols
may be used.
Key Function
Esc • Cancels key input and returns to previous display screen.
• Long push to return to the standby display.
F1 - F10 Select menus. See section 2.2.3.
BackSpace Deletes the character to the left of the cursor.
Ins Works the same as “paste.” See “How to cut and paste text” in
section 4.2.4.
Del Deletes the character selected with the cursor.
Home Moves the cursor to the top of the message being edited.
End Moves the cursor to the bottom of the message being edited.
PgUp Goes to the previous page of the edit screen.
PgDn Goes to the next page of the edit screen.
↑, ↓, ←, → Control the cursor.
Enter Registers key input; inserts carriage return in TX message.
Shift Selects upper or lower case alphabet. Press and hold down the key
and then press the [Caps Lock] key to get upper or lower case alpha-
bet. Note that only upper case alphabet are used in telex.
Alt Provides the shortcut key operation when combined with an alphabet
key. See section 2.2.2.
Spacebar Inserts a space. In addition, it displays the file list, a partial view of a
file, etc., depending on menu.
Caps Lock Turns upper case alphabet input on or off. The Caps Lock LED lights
when upper case alphabet input is on.
Tab Inserts horizontal tab characters. The number of tab characters the
key can insert per line of text can be programmed for two, four or eight
tabs.
Ctrl Works in combination with alphabet keys as follows:
• Ctrl + [M]: Same as Enter.
• Ctrl + [H]: Same as Back Space.
• Ctrl + [I]: Same as Insert.
• Ctrl + [V]: Same as Overwrite+Insert on Edit Mode in the Editor Set-
up menu.
NumLk Turns numeric input on or off. Note that you cannot enter alphabet
when the NumLk LED is lit.
