6. DATA REPORT AND POLLING
6-6
2. Press the 1, 2, 3 or 4 key to select a message report and show the following menu.
3. [PIN Code] is selected; press the Enter key to open the PIN code entry window.
4. Enter PIN code number (max. 8 digits) then press the Enter key.
5. Follow the procedure from step 5 on page 6-3.
6.2.2 Other polling commands
Telex: P???/PIN Code/TELEX/LES number/Country number/Subscrib-
er’s number/File name:
E-mail: P???/PIN Code/EMAIL/LES number/ E-mail address/File name:
Public Switched
Telephone Network:
P???/PIN Code/PSTN/Modem type/LES number/Country num-
ber/Subscriber’s number/File name:
Modem type is selected from T30, V21, V22B, V22, V23, V26B,
V26T, V27T or V32.
Packet Switched
Data Network:
P???/PIN Code/PSDN/LES number/Country number/Subscrib-
er’s number/File name:
Data Network
Identification:
P???/PIN Code/DNID/LES number/Subscriber’s number/File
name:
Facsimile: P???/PIN Code/FAX/LES number/Country number/Subscriber’s
number/File name:
2-digit telex
service:
P???/PIN Code/SPEC/LES number/Country number/Subscrib-
er’s number/File name:
For ship-to-ship communication, country number is ocean region
number. Subscriber’s number includes Station ID, Telex ID, etc. If
file name is not specified (/:), position, speed, bearing, water tem-
perature, current and depth are transmitted. Furthermore, / is de-
leted (:), position, speed and bearing are transmitted.
For example, you transmit polling command to MES of PIN code
12345678 via KDDI station (Pacific Ocean: 203) specifying telex
number 720-5644325. Then, that MES transmits position, speed,
bearing, water temperature, current and depth.
P???/12345678/TELEX/203/720/5644325/:
To have other MES transmit position, speed and bearing by e-
mail to abc@furuno.co.jp, for example, use the following com-
mand.
P???/12345678/EMAIL/203/abc@furuno.co.jp:
Message Report
OFF
PIN Code
Message Report Programming
Status
Station Name
To Next Page
