3-1
3. SYSTEM INITIALIZATION
This chapter shows you how to initialize the FELCOM system. Once the equipment is
initialized, you need do no more than press a few keys to get fully automatic transmis-
sion and reception.
Inmarsat assigns an MES (your ship) an Inmarsat Mobile Number (IMN) when it ap-
plies for Inmarsat registration. The IMN is necessary to communicate in the Inmarsat
system and It is entered into the FELCOM system during the installation.
3.1 System Settings
3.1.1 Confirm the main terminal
The main terminal is where you set up the system. (You cannot set up the system from
an external terminal.) Confirm that the main terminal is selected as below.
1. Press the F8 key to show the [Setup] menu.
If your screen looks something like the one shown in the illustration above, you are
using the main terminal. (If you are using an external terminal, some menu items ap-
pear in gray.)
3.1.2 System setup
The [System Setup] menu is where you enter the date, time, operating mode, and port
function.
1. Press the F8 and 1 keys to show the [System Setup] menu.
2. [System Date & Time] is selected; press the Enter key to open the date entry win-
dow.
3. Enter the date with the numeric keys. (Entry of date is not necessary if a GPS nav-
igator is connected to the FELCOM.)
Setup
1. System Setup
2. Editor Setup
3. Terminal Setup
4. EGC Setup
5. Auto Mode Setup
6. E-Mail Setup
7. Directories
8. Configuration
System Setup
03:11 11-12-25 (YY-MM-DD)
123456789
INMARSAT-C
EXT
ON
INT
INT
System Date & Time
IMN
MES Operation Mode
Nav Port
LAN Port
Message Output Port
EGC Output Port
Network Setup
Command Window
Entered at installation
(Cannot be changed.)
For the serviceman
To Next Page
