0
Normal
+1 ~ +100
Trigger operation
Quick
-1 ~ -100
Mild
Servo travel
Vertical cursor moves in step
with throttle trigger operation.
59
Function
Exponential Adjustment "EXP"
(Preparation)
- On the EXP screen make the following adjustments:
1
Select the setting item "BRK"
by moving the (JOG) button up or
down.
Use the (+) button to adjust for a faster brake response
or use the (-) button for a slower or milder brake response.
Throttle brake side EXP adjustment
Adjustment range
-100 ~ 0 ~ +100%
Adjustment buttons
- Use the (+) and (-) buttons to
make adjustments.
- Return to the initial value by
pressing the (+) and (-) buttons
simultaneously (approx. 1 sec).
The steering and throttle EXP adjustment (RATE) can be controlled with digital dial
or digital trim. With the function select
trim dial
function (See page 70).
Dial / Trim Setting
2
When finished with setting, return to the MENU screen by
pressing the (END) button.
