FUTABA 4PV - CPS Mixing CPS MIX

(HOME screen)
(MENU 1)
(MENU 3)
(CPS MIX screen)(MENU 2)
Pres
s
Pres
s
Pres
s
Select
" CPS MIX "
86
Function
CPS Mixing "CPS MIX"
Display
"
CPS MIX
"
screen using the following method:
This function controls the Futaba CPS-1 channel power switch.
Normally, when using the CPS-1 unit to operate vehicle lighting systems, the CPS-1 unit
with LED connected is connected to a vacant switch channel and the LEDs are turned on
and off by switch while the vehicle is running. However, when the CPS-1 mixing (CPS
0,;IXQFWLRQLVXVHGWKH/('FDQEHWXUQHGRQDQGRIIDQGÀDVKHGLQVWHSZLWKVWHHULQJ
DQGWKURWWOHRSHUDWLRQDVZHOODVEHLQJWXUQHGRQDQGRIIE\VZLWFK7KHÀDVKLQJVSHHGF\FOH
can also be set.
)RULQVWDQFHWKH/('FDQEHÀDVKHGDVDEUDNHOLJKWE\WKURWWOHEUDNHVLGHRSHUDWLRQ
CPS Mixing "CPS MIX"
:KHQWKHWK&+LVVHWWR$&7E\%UDNH0L[LQJSRUZKHQ6WHHULQJ0L[LQJS
and Dual ESC Mixing (p.82) are used, this CPS Mixing function cannot be used.
Setting Special Mixes
(Preparation)
- Connect the CPS-1 to the 4th CH of the receiver.
- When the LEDs are turned on and off by switch, use the func-
tion select switch function (p.72) to set the switch to be used.
CPS mixing adjustment
Function SW
CH4
Setup items
MODE : Function ON/OFF, control mode
POSI :
ON/OFF position
TYPE : ON/OFF type
TCYCL : Flashing speed
