Function
Steering Mixing "STR MIX"
1
(Steering mixing function ON/OFF)
Select the setting item "MODE" by moving the (JOG) button up
or down. Set the function by pressing the (+) or (-) button.
"
INH
"
: Function OFF.
"
ACT
"
: Function ON.
- When
"
(ESC INH)
"
is displayed, the STR MIX cannot be used if the DUAL ESC
function is not set to
"
INH
"
.
- When
"
(CPS INH)
"
is displayed, the STR MIX cannot be used if the CPS function is
not set to
"
INH
"
.
- When
"
(BRK4 INH)
"
is displayed, the STR MIX cannot be used if the BRAKE
MIX (CH4) function is not set to
"
INH
"
.
2
(Steering 1 rate)
Select the setting item STR 1 "LFT" or "RGT" by moving the
(JOG) button up or down. Adjust the left and right steering
amounts using the (+) or (-) button.
3
(Steering 2 rate)
Select the setting item STR 2 "LFT" or "RGT" by moving the
(JOG) button up or down. Adjust the left and right steering
amounts using the (+) or (-) button.
4
(Ackerman adjustment)
Select the setting item "ACKERMANN" rate by moving the
(JOG) button up or down.
Adjust the left and right differential amount and adjust the Ack-
erman by (+) and (-) button.
5
When finished with setting, return to the MENU screen by
pressing the (END) button.
Steering mixing adjustment
$FNHUPDQUDWHFDQEHFRQWUROOHGZLWKGLJLWDOGLDORUGLJLWDOWULPXVLQJWKHIXQFWLRQVH-
lect trim dial function (See page 70).
Dial / Trim Setting
Function ON/OFF (MODE)
INH, ACT
Select button
- Select with the (+) or (-) but-
tons.
Adjustment buttons
- Use the (+) and (-) buttons to
make adjustments.
- Return to the initial value by
pressing the (+) and (-) buttons
simultaneously (approx. 1 sec).
Sterring 1 rate
(STR 1 LFT,RGT)
0 ~ 120
Initial value:100
Adjustment buttons
- Use the (+) and (-) buttons to
make adjustments.
- Return to the initial value by
pressing the (+) and (-) buttons
simultaneously (approx. 1 sec).
Sterring 2 rate
(STR 2 LFT,RGT)
0 ~ 120
Initial value:100
Adjustment buttons
- Use the (+) and (-) buttons to
make adjustments.
- Return to the initial value by
pressing the (+) and (-) buttons
simultaneously (approx. 1 sec).
Ackerman rate
-100 ~ 0 ~ +100
Initial value:0
