FUTABA 4PV - Page 77

77
Function
Brake Mixing "BRAKE"
1
(Brake mixing function ON/OFF)
Select the setting item "MODE" of <CH3> for CH3 brake and
"MODE" of <CH4> for CH 4 brake by moving the (JOG) button
up or down, and use the (+) or (-) buttons to set the function to
the "ACT" state.
"
INH
"
: Function OFF.
"
ACT
"
: Function ON.
- When
"
(4WS OFF)
"
LVGLVSOD\HGEHORZ&+!$%6WKH&+EUDNHFDQQRWEHXVHG
if the 4WS function is not set to
"
OFF
"
.
- When
"
(ESC INH)
"
LVGLVSOD\HGXQGHU&+!$%6WKH&+EUDNHFDQQRWEHXVHG
if the DUAL ESC function is not set to
"
INH
"
.
- When
"
(SMX INH)
"
LVGLVSOD\HGXQGHU&+!$%6WKH&+EUDNHFDQQRWEHXVHG
if the STR MIX function is not set to
"
INH
"
.
2
(Brake rate)
Moving the (JOG) button up or down, select "RATE" of <CH3>
for CH3 brake and "RATE" of <CH4> for CH 4 brake, and use
the (+) and (-) buttons to adjust the Brake rate amount.
3
(Delay amount setup)
Moving the (JOG) button up or down, select "DELY" of <CH3>
for CH3 brake, "DELY" of <CH4> for CH 4 brake and "DELY" of
<CH2> for CH 2 brake. Use the (+) and (-) buttons to adjust the
delay amount.
"
0
"
: No delay.
"
100
"
: Maximum delay amount.
4
(3rd & 4th channels brake-A.B.S ON/OFF)
Moving the (JOG) button up or down, select "ABS" of <CH3>
for CH3 brake and "ABS" of <CH4> for CH 4 brake.
Use the (+) or (-) key and set the function to the "ACT" state.
5
When finished with setting, return to the MENU screen by
pressing the (END) button.
Brake mixing adjustment
Adjustment buttons
- Use the (+) and (-) buttons to
make adjustments.
- Return to the initial value by
pressing the (+) and (-) buttons
simultaneously (approx. 1 sec).
Brake rate (RATE)
0 ~ 100
Initial value:100
Delay amount (DELY)
(CH3) 0 ~ 100
(CH4) 0 ~ 100
(CH2) 0 ~ 100
Initial v
alue:0
Function ON/OFF (MODE)
INH, ACT
Function ON/OFF (ABS)
INH, ACT
7KHIXQFWLRQVHOHFWGLDOIXQFWLRQFDQFRQWUROWKHUGWKFKDQQHOVEUDNHUDWH5$7(
can be controlled with digital dial or digital trim, using the function select trim dial
function (See page 70).
Dial / Trim Setting
,QRUGHUWRXVH&+RIWKHEUDNHPL[LQJIXQFWLRQLWLVQHFHVVDU\WRVHW:6S
and Gyro MIX (p.84) to the
"
INH
"
setting. In order to use 4CH, it is necessary to set
STR MIX (p.74), Dual ESC (p.82) and CPS MIX (p.86) to the
"
INH
"
setting.
Setting Special Mixes
Select button
- Select with the (+) or (-) but-
tons.
Select button
- Select with the (+) or (-) but-
tons.
