D-4 CASE Revision C
2060290-201
Technical Description: Technical Specifications – CASE System
Dynamic range 320 mV, ±10 mV signal superimposed on ±150 mV DC offset
Resolution 4.88 µV/LSB @ 500 Hz
Noise < 15 µV peak-to-peak noise over 0.01 to 150 Hz (-3 dB) bandwidth
Frequency response - 3dB, display and writer
High pass filter 0.01 Hz (or 0.05 Hz, special use) with DC offset control
Low pass filter 20, 40, 100 or 150 Hz (selectable)
Line filter 50.0 or 60.0 Hz notch filter (selectable)
Baseline correction Cubic spline algorithm
Artifact/baseline correction Finite Residual Filter (FRF) algorithm
Common mode rejection > 140 dB (123 dB with AC filter disabled)
Input impedance > 10 MΩ @ 10 Hz, defibrillator protected
Patient leakage < 10 µA
Pace detect Orthogonal LA, LL, and V6; 750 µV @ 50 µs
Communication/storage
MUSE CV system compatible via diskette or SD card, network (optional)
MUSE CV Web compatible for retrieval, view, printing of MUSE CV
system data
Local storage: minimum 10 GB hard drive storage of complete ECG
record and test results
DVD-RW removable archive (optional)
PDF export of final reports
Microsoft Word export of configured reports
XML or Excel export of special data
Table 3. Display
Item Description
Type LCD
Resolution 1680 x 1050 (22'' monitor)
1280 x 1024 (19'' monitor)
Table 2. Performance Specifications – Data Acquisition (Continued)
Item Description
