Revision C CASE D-5
2060290-201
Technical Description: Technical Specifications – CASE System
Size 22'' diagonal DVI (22'' monitor)
19'' diagonal DVI (19'' monitor)
Monitored leads 3, 6, or 15
Displayed leads 3, 6, 12 or 15 (Resting ECG) and 3 or 6 (Stress Test)
Format 3 rhythm, 3 rhythm + medians, 3 rhythm + trends, 6 rhythm,
4 x 2.5 + 1 rhythm, 2 x 6
Speeds 25, 50 mm/s
Sensitivity/Gain 2.5, 5, 10, 20 mm/mV
Displayed vital signs data
(configurable)
Heart rate, target heart rate, blood pressure, exercise clock, stage clock,
phase clock, protocol, speed, grade, Watts, METS, RPP, and SpO
2
Other displayed data ST scan/median complexes, arrhythmias, ventricular ectopic/min. counter,
3 to 15 waveforms, lead check torso and 12 leads, waterfall displays, trends,
tabular summary, stored ECG strips, interpretation, time-of-day clock, patient
name, warning messages and prompts
Table 3. Display (Continued)
Item Description
