GE LOGIQ E10 Service Manual

DIRECTION 5750007-1EN, REV. 1 LOGIQ E10 BASIC SERVICE MANUAL
8 - 32 Section 8-6 - Replacing Covers and Bumpers
8-6-2 Covers and Bumpers overview (cont’d)
Table 8-20 Covers and Bumpers for LOGIQ E10
PART NAME ILLUSTRATION QTY PART NAME ILLUSTRATION QTY PART NAME ILLUSTRATION QTY
Left Side Cover
Assembly/Air
Intake
See: 8-6-3 "Side
Cover(s)/Side Air
Intake (Filter)
inspection /
replacement" on
page 8-33.
1
Rear Bumper/Air
Intake
See: 8-6-8 "Rear
Bumper/Air Intake
(Filter) inspection /
replacement" on
page 8-49.
1
Bulkhead Cover
See: 8-6-18
"Bulkhead Cover
replacement" on
page 8-79.
1
Right Side Cover
Assembly/Air
Intake
See: 8-6-3 "Side
Cover(s)/Side Air
Intake (Filter)
inspection /
replacement" on
page 8-33.
1
Top Cover
See: 8-6-10 "Top
Cover
replacement" on
page 8-55.
1
Main Monitor Arm
Plastic
Covers (for,
Ergotron Arm
Assembly). See:
8-6-13 "Main
Monitor Arm
Assembly Covers
replacement" on
page 8-64.
Contains:
1. Pan Arm Down
Cover
2. Lift Arm Cover -
Right
3. Lift Arm Cover -
Left
4. Joint Cover
5. Extension Arm
Cover
6. Rotation Limit
Screw
1
Foot Rest Bumper
See: 8-6-5 "Foot
Rest Bumper
replacement" on
page 8-41.
1
Rear Handle
See: 8-6-12 "Rear
Handle
replacement" on
page 8-62.
1
Caster Hubcap
(cover)
See: 8-10-4
"Caster Hubcap
replacement" on
page 8-236.
4
Front Cover
See: 8-6-4 "Front
Cover
replacement" on
page 8-38.
1
Printer Filler
Storage
See: 8-6-14
"Printer Filler
Storage
replacement" on
page 8-66.
1
Pedal Mechanism
Covers:
Parking Brake (1)
Swivel Lock (2)
See: 8-10-7
"Pedal
Mechanism
Covers
replacement" on
page 8-250.
1
Rear Cover/Air
Exhaust
See: 8-6-7 "Rear
Cover/Air Exhaust
replacement" on
page 8-45.
1
Cover, Main
Cable
See: 8-6-16 "Main
Cable Cover
replacement" on
page 8-73.
1
Rear Cover Trim
See: 8-6-9 "Rear
Trim Cover
replacement" on
page 8-52.
1
Column Cover Kit
See: 8-6-15
"Column Cover
Assembly
replacement" on
page 8-69.
1
1
3
2
4
5
6
1
2
