Chapter 6: Illustrated Parts
Harness List
Service Manual 6-21
6.9 Harness List
Description Part Number
OEM part, harness, warmer LCD 6600-1412-600
Harness, Heater/T-Stat/Power Supply 6600-1558-700
Harness, 115vac Halogen Transformer 2065752-001
Harness, 230vac Halogen Transformer 2065756-001
Harness, Ebase Power Cord (Bedded Models Only) 6600-1562-700
Harness, Speaker 6600-1563-700
Harness, Thermalink 6600-1564-700
Harness, Control Brd Power 6600-1567-700
Harness, Patient Probe 6600-1572-702
Harness, Door Switch, Battery, Speaker 6600-1573-700
Harness, Mains Power 6600-1574-700
Harness, Scale Rail 6600-1586-700
Harness, SpO
2
Rail (Bedded Model Only) 6600-1587-700
Wire Harness Warmer Observation Light Switch 6600-1588-700
Harness, Obso Light 6600-1594-700
Harness, Control Board Ribbon 6600-1411-601
Harness, Alarm Board Signal 6600-1411-602
Harness Warmer Foot Switch Signals M1073604
Harness, Warmer, Over-Temp T-Stat M1074875
Harness Line Filter M1107967
Harness, Power Factor M1113026
Harness, Ground wire, Patient Probe Plate M1113148
Power Supply Bracket Ground M1126279
Rail Ground M1126289
Heater Duct Ground M1126291
Dish Ground M1126293
Masimo SET 2 SpO2 Flex Circuit M1233644
Nellcor SpO
2
Flex Circuit M1233645
SpO
2
Shield Ground Wire M1144733
