Chapter 6: Illustrated Parts
Labels
6-32 Service Manual
6.11.6 Labels on Wall Mount Model
Note: When installing the mattress height label on the wall, place the bottom bar of the label (indicating
the minimum height) at 32” +/- .1” (81.30 cm +/- .25 cm) from the floor and vertically center align the
label with the center of the warmer head. See Figure E-7.
A B C D
! !
! !
! !
! !
MAX 2A @ 115v~, 50/60 Hz
MAX 1A @ 220-240v~, 50/60 Hz
w
Accessory load label M1110852
Speaker bafling (see
table next page)
Heater head warning label
(See next page)
Rating Label (see table next page)
Breaker ON/OFF (see table next page)
Rail load label (see table next page)
Mattress height
label (only one
label to be placed
on the wall)
2062951-001
Mattress height
warning label (one
label to be placed
on the wall next to
mattress height
label) 2070456-001
