Chapter 1: Functional Description
Introduction
Service Manual 1-5
Feature
Number
Description Model
9 Recessed radiant heater All
10 Side bedside panel (bed styles are different on Giraffe and Panda) Bedded
11 Front handle Bedded
12 Pass through drawer, (single-drawer or double-drawer) (optional) Bedded
13 Two bed height adjustment pedals, up and down (optional) Bedded
14 Caster wheels, 3 for Freestanding, 4 for Bedded Bedded and Freestanding
15 Brakes, 2 for Freestanding, 4 for Bedded Bedded and Freestanding
16 Elevating column (optional) Bedded
17 Tank guard (on models with yoke equipped resuscitation systems) Bedded and Freestanding
18 Scale cable connector Bedded
19 Temperature probe Jack All
20 High pressure air/oxygen yoke (on models with yoke equipped
resuscitation systems
Bedded and Freestanding
21 Maneuvering handle and cord wrap Bedded and Freestanding
22 Dovetail rail (shortened on Wall Mount, only inside on Freestanding) Bedded and Freestanding
FIGURE 1-2. Panda Warmer, Side View
9
22
21
20
19
18
17
16
15
14
13
12
11
10
