GE RSTi-EP - Page 168

Chapter 5 Detailed Descriptions of I/O Modules
GFK-2958E RSTi-EP User Manual 164
General data
Weight
83 g (2.93 oz)
For additional general data, refer to the section General Technical Data for I/O Modules.
Overview of the Editable Parameter EP-5111
Channel
Description
Options
Default
Diagnostic alarm
disabled (0) / enabled (1)
disabled
0
Filter time signal A
0,01 ms [100 kHz] (0) / 0,017 ms [50 kHz] (1) / 0,033 ms [30 kHz] (2)
/ 0,1 ms [10 kHz] (3) / 0,2 ms [5 kHz] (4) / 0,5 ms [2 kHz] (5) / 1 ms
[1 kHz] (6)
0,01 ms
0
Filter time signal B
0,01 ms [100 kHz] (0) / 0,017 ms [50 kHz] (1) / 0,033 ms [30 kHz] (2)
/ 0,1 ms [10 kHz] (3) / 0,2 ms [5 kHz] (4) / 0,5 ms [2 kHz] (5) / 1 ms
[1 kHz] (6)
0,01 ms
0
Filter time latch
0,01 ms (0) / 0,017 ms (1) / 0,033 ms (2) / 0,1 ms (3) / 0,2 ms (4) /
0,5 ms (5) / 1 ms (6)
0,01 ms
0
Filter time gate
0,01 ms (0) / 0,017 ms (1) / 0,033 ms (2) / 0,1 ms (3) / 0,2 ms (4) /
0,5 ms (5) / 1 ms (6)
0,01 ms
0
Filter time reset
0,01 ms (0) / 0,017 ms (1) / 0,033 ms (2) / 0,1 ms (3) / 0,2 ms (4) /
0,5 ms (5) / 1 ms (6)
0,01 ms
0
Process alarm HW
gate open
disabled (0) / enabled (1)
disabled
0
Process alarm HW
gate closed
disabled (0) / enabled (1)
disabled
0
Process alarm
overflow
disabled (0) / enabled (1)
disabled
0
Process alarm
underflow
disabled (0) / enabled (1)
disabled
0
Process alarm comp.
value
disabled (0) / enabled (1)
disabled
0
Process alarm end
value
disabled (0) / enabled (1)
disabled
0
Process alarm latch
value
disabled (0) / enabled (1)
disabled
0
Counting mode
count endless (0) / once - forward (1) / once - backwards (2) /
once - no main direction (3) / periodic - forward (4) / periodic -
backwards (5) / periodic - no main direction (6)
count
endless
0
Condition for DO
disabled (0) / higher equal comparison value (1) / lower equal
comparison value (2)/ equal comparison value (3)
disabled
0
Counter dir. signal B
inv.
disabled (0) / enabled (1)
disabled
0
Reset
disabled (0) / high level (1) / rising edge 0-1 (2)/
rising edge once 0-1 (3)
0
Signal mode
Rotary transducer - single (0) / Rotary transducer - double (1) /
Rotary transducer - quadruple (2) / Pulse
and Direction (3) / disabled (4)
disabled
0
HW gate
disabled (0) / enabled (1)
disabled
0
Counter behavior
internal gate
Interrupt counting (0) / Cancel counting (1)
interrupt
counting
0
End value
-2147483648 to 2147483647
2147483647
0
Load value
-2147483648 to 2147483647
0
0
Hysteresis
0 to 255
0
