Chapter 5 Detailed Descriptions of I/O Modules
GFK-2958E RSTi-EP User Manual 165
0
Pulse duration
0 to 255 [Input value x 2 = output time; corresponds to 0 ... 510
ms]
0
Note: The parameter setting in the network adapter for the Behavior of outputs on fieldbus error
affects the control word and thus the behavior of the EP-5111:
• The Hold last value setting
The output continues working or switches as prametrized respectively.
The counter continues to count during the error. Once normal operating conditions have
been restored, the counter continues to count starting at the previous value.
• The Enable substitute value setting
The output is switched off.
The counter value is frozen. Once normal operating conditions have been restored, the
counter value is reset to the parameterised load value.
• The All outputs off setting
The output is switched off. The counter behaves in the same way as for Hold last value.
Diagnostic Data EP-5111
Name
Bytes
Bit
Description
Default
Error indicator
0
0
Module error
1
Internal error
2
External error
3
Channel error
4
External auxiliary supply error
5
Reserved
0
6
Reserved
0
7
Parameter error
Module type
1
0
Module Type
0x08
1
2
3
4
Channel information available
1
5
Reserved
0
6
Reserved
0
7
Reserved
0
Error byte 2
2
0-7
Reserved
0
Error byte 3
3
0-2
Reserved
0
3
Internal diagnostic FIFO full
4
Reserved
0
5
Reserved
0
6
Process alarm lost
7
Reserved
0
Channel type
4
0-6
Channel type
0x76
