Rack and pinion hoist
Assembly and Operating Instructions
35 / 100 BL108 GB Edition 03.2018 Rev. 02
Assembly in front of a wall
Anchoring distance V = 4m
Load capacity = max. 200kg
Anchoring forces with maximum track projection
The values in the table apply for each anchorage point
