Gehl RT210 User Manual

Troubleshooting
50940411/G0219 172 Printed in U.S.A.
Miscellaneous Troubleshooting
Error Codes
The tables in this section describe error codes which may be reported on the multi-function display screen.
More than one error can be reported at one time, and each error code will display on a separate screen.
Multiple errors will be reported on a summary screen. See “Multi-Function Display” on page 48.
NOTE:
Error codes remain displayed after the error is corrected. Press the display several times to rotate
through all display screens to refresh the display; corrected error codes will not reappear in the screen
rotation.
Controller Communication Error Codes
NOTE: See “Control Modules” on page 158 for controller locations.
Engine Error Codes
Models RT175/RT210 Yanmar Engine Diagnostic Trouble Codes (DTC)
Table 53: Miscellaneous Troubleshooting
Problem Possible Cause Corrective Action
Non-functional cab heater
Thermostat oriented in housing with
support bales/arms blocking feed hole to
heater hose. (SOME heat delivered
through heater)
Replace thermostat; align bales/arms
properly (parallel to engine crankshaft) in
housing.
Table 54: Controller Communication Error Codes
Error Code Error Description
1-2 No Communication between engine control module to display
1-3 No Communication between drive / lift arm / standard aux. flow control module to display
1-4 No Communication between display to main / drive control module
1-5 No Communication between multi-function control module to display
27 No CAN communication engine control module to main / drive control module
28 No CAN Communication main / drive control module to display
29 No CAN Communication drive / lift arm / standard aux. flow control module to main / drive control module
Table 55: Yanmar Engine Diagnostic Trouble Codes (DTC)
DTC Error Item
SPN FMI P-Code Part State
28 0 P1126 Acceleration Sensor 3 Sensor failure (throttle in open position)
28 1 P1125 Acceleration Sensor 3 Sensor failure (throttle in closed position)
28 2 P0224 Acceleration Sensor 3 Intermittent fault
28 3 P0223 Acceleration Sensor 2 Acceleration sensor 2 fault (high voltage)
28 4 P0222 Acceleration Sensor 2 Acceleration sensor 2 fault (low voltage)
29 0 P1226 Travel Pedal Position Sensor "B" Above normal operation range
29 1 P1225 Travel Pedal Position Sensor "B" Below normal operation range

Gehl RT210 Specifications

General

Rated Operating Capacity	2, 100 lbs
Engine Make	Yanmar
Tipping Load	6000 lbs
Displacement	202 cu in
Hydraulic Pressure	3335 psi
Width	72 in
