Gehl RT210 User Manual

Specifications
50940411/G0219 44 Printed in U.S.A.
Electrical System
Sound Power/Pressure Levels
Vibration Levels
Total Boom - Cycle Time 12.8 seconds 13.5 seconds 13.6 seconds
Table 14: Hydraulic System : Forces and Cycle Times
Table 15: Electrical System
RT175 RT210 RT250
Glow Plug (Engine Pre-heat) Auto w/glow lamp
Backup Alarm 112 + 4 dB(A)l 2500 + 300 Hz
Battery
Type Maintenance-free
Volts 12 V
Group Size 65 31
Cold Cranking Amps @ Temperature 850 CCA @ -18°C (0°F) 950 CCA @ -18°C (0°F)
Minimum Reserve Capacity 140 minutes
Table 16: Sound Power/Pressure Levels
RT175
(interim Tier 4
Engine)
RT175
(Tier 4 Engine)
RT210
(interim Tier 4
Engine)
RT210
(Tier 4 Engine)
Noise Level / Environmental Level (EU
Dir. 2000/14/EC)
103 dB(A) 101 dB(A) 103 dB(A) 101 dB(A)
Operator Ear (EU Dir. 2006/42/EC) 82 (+
2.2) dB(A) 82 dB(A) 83 (+2.8) dB(A) 78 dB(A)
Table 17: Vibration Levels
RT175 RT210
Whole-Body Vibration (ISO 2631-1) <
0.74 m/s² (+ 0.37k) < 0.79 m/s² (+ 0.40k)
Hand-Arm Vibration (ISO 5349-1) <
3.5 m/s² (+ 1.75k) < 4.4 m/s² (+ 2.2k)

Gehl RT210 Specifications

General

Rated Operating Capacity	2, 100 lbs
Engine Make	Yanmar
Tipping Load	6000 lbs
Displacement	202 cu in
Hydraulic Pressure	3335 psi
Width	72 in
