Specifications
Printed in U.S.A. 39 50940411/G0219
Weights
Track Drive
Coolant Compound Table
Table 6: Weights
RT175 RT210 RT250
Operating Mass (standard counterweight)
1
3903 kg (8605 lbs.) 4445 kg (9800 lbs.) 5203 kg (11 470 lbs.)
Operating Mass (optional counterweight)
1
4044 kg (8915 lbs.) 4590 kg (10 120 lbs.) 5520 kg (12 170 lbs.)
Shipping Weight (standard counterweight) 3556 kg (7840 lbs.) 4028 kg (8880 lbs.) 4996 kg (11 015 lbs.)
Shipping Weight (optional counterweight) 3697 kg (8150 lbs.) 4132 kg (9110 lbs.) 4736 kg (10 440 lbs.)
1. Equipped with standard bucket, driver and full fluids.
Table 7: Track Drive
RT175 RT210 RT250
Gradeability 30°
Brakes Mechanical / hydraulic; spring applied / hydraulically released
Tractive effort 4498 kg (9917 lbs.) 5211 kg (11 489 lbs.) 5792 kg (12 770 lbs.)
Track Type / Track Rollers / Roller Type Rubber / 3 / steel Rubber / 4 / steel
Track Dimensions (standard)
320 mm x 86 mm (12.5
in. x 3.4 in.) x 54
Pitches
450 mm x 86 mm (17.7
in. x 3.4 in.) x 56
Pitches
450 mm x 86 mm (17.7
in. x 3.4 in.) x 58
Pitches
Track Dimensions (optional)
400 mm x 86 mm
(15.75 in. x 3.4 in.) x 54
Pitches
N/A
Track Ground Contact Length 1395 mm (55 in.) 1483 mm (58.4 in.) 1562 mm (61.5 in.)
Ground Pressure (standard track)
0.44 kg/cm
2
(6.2 psi) 0.33 kg/cm
2
(4.7 psi) 0.37 kg/cm
2
(5.3 psi)
Ground Pressure (optional track)
0.35 kg/cm
2
(5.0 psi)
N/A
Number of Track Rollers 3 (per side) 4 (per side)
Travel Speed
Low: 8.5 kph (5.3 mph)
High: 12.4 kph (7.7
mph)
Low: 9.8 kph (6.1 mph)
High: 14.3 kph (8.9
mph)
Low: 9.3 kph (5.8 mph)
High: 13.2 kph (8.2
mph)
Table 8: Coolant Compound Table
Outside Temperature Water Anti-corrosion agent Antifreeze
Up to °F (°C) % by volume in³/gal (cm³/L) % by Volume % by volume
39 (4) 99
2.6 (10) 1
–
14 (- 10) 79 20
-4 (- 20) 65 34
-13 (- 25) 59 40
-22 (- 30) 55 45
-44 (-42) 50 50
